Eden 5 Powered

Eden 5 Powered	22	24	26	28	30	33
Zoom flat [%]	87	92	95.7	100	104	108
Area flat [m²]	21.78	23.8	25.75	28.12	30.41	33.41
Area projected [m²]	19.45	21.25	23	25.11	27.16	29.83
Span flat [m]	11.04	11.55	12.01	12.55	13.05	13.68
Aspect ratio flat	5.6	5.6	5.6	5.6	5.6	5.6
Root cord [m]	2.42	2.53	2.63	2.75	2.86	3
Cells	52	52	52	52	52	52
Weight [kg]	4.7	4.95	5.2	5.6	6	6.4
Weight range free flight *[kg]	60 - 75	67 - 85	75 - 95	85 - 110	105 - 130	115 - 145
Weight range free flight * [lbs]	132 - 165	148 - 187	165 - 209	187 - 243	231 - 287	254 - 320
Weight range powered *[kg]	77 - 100	89 - 113	100 - 127	113 - 147	140 - 180	153 - 193
Weight range powered *[lbs]	170 - 220	196 - 249	220 - 280	249 - 324	309 - 397	337 - 425
Min. speed [km/h]	23 - 25	23 - 25	23 - 25	23 - 25	23 - 25	23 - 25
Trim speed [km/h]	36 - 38	36 - 38	36 - 38	36 - 38	36 - 38	36 - 38
Top speed (accelerator)[km/h]	48 - 50	48 - 50	48 - 50	48 - 50	48 - 50	48 - 50
Glide ratio	9.7	9.7	9.7	9.7	9.7	9.7
Min. sink rate [m/s]	1.05	1.05	1.05	1.05	1.05	1.05
Certificate free flight	LTF/EN-B	LTF/EN-B	LTF/EN-B	LTF/EN-B	LTF/EN-B	LTF/EN-B
Certificate powered	DGAC	DGAC	DGAC	DGAC	DGAC	DGAC
* powered pilot equipped = weight naked + cca. 35 - 40 Kg (73 - 88 lbs)

Technical Specifications
