Product Description

X-Dreamer

Share

The X-Dreamer is our new modern open harness. It meets the highest standards of the most demanding pilots.

The X-Dreamer is suitable from the beginner pilot to the cross country or experienced pilot. It provides a positive influence to the pilot’s confidence. The ergonomic design focuses on comfort and simplicity. The overall geometry of the harness enables the pilot to feel the feedback from the glider sensitively, whilst retaining a secure feeling in flight. This increases the precision of turns while thermaling and aids active flying. On long flights, the comfort of the X-Dreamer is second to none.

The geometry of the X-Dreamer greatly simplifies takeoffs and landings. Leg’s strap system and sliding shoulder straps enable to stand and run completely upright by takeoff and landing. Thanks use of different materials on the seat board it is easy to slide into the seat after takeoff. The X-Dreamer is ideal for ground handling.

The harness is serial delivered with two self-locking carabineers, 2 protectors, carbon plate and 2 step speed system led in tube system. Leg and chest straps are integrated into 2 buckle closing system. Newly fitted with Cobra buckles.

Protectors

The X-Dreamer can newly be equipped with certified inflatable back protector. This provides a better fit of the harness to backpacks of smaller volume.

The lower frontal foam protector forms the shape of the harness and is located beneath the space of the rescue system.

X-Dreamer

On order, the harness can be equipped with former certified foam protector. The back protector is 17 cm thick.

In some countries it is allowed to fly without a rescue system up to 80m height over the ground. E.g. First short flights in the teaching process in the school or personal training of ground handling. For these purposes the rescue pocket can be optionally fitted with third additional foam protector for added passive safety. With this additional foam protector the laboratory tests show even further improved G resistance.

The X-Dreamer is available in four sizes (S, M, L and XL) that fit to pilot’s height starting from 155 cm up to 200 cm. Volume space for the rescue: 10,0 dm3 Harness weight: starts on 4.00 kg.

The X-Dreamer harness was load tested to 15 g of max. weight 120 kg.

Technical Specifications

characteristics Value
Max. load: 120 kg
Karabiner distance: 39-54,5 cm
Weight incl. carabiners
& foam protector:
S - 4.3 kg M - 4.35 kg
L - 4.45 kg XL - 4.6 kg
Back protection: Certified inflatable back protector;
17 cm
Rescue system: Integrated container (tunnel system)
under the seat plate with a lateral handle.
Size pilot
S up to 165 cm
M 165 - 175 cm
L 175 - 185 cm
XL 185 cm and up

Features of the X-Dreamer:

  • light construction with 2 buckle closing system COBRA buckles
  • carbon seat plate, adjustable angle of the seat
  • two carabineers Lock Jaw
  • 2 step speed bar & lines & Brummel hooks
  • certified inflatable back protector
  • shoulder strap Velcros (e.g. for small varios)
  • reserve V-connection channel with zip
  • outside zip-up on the left side
  • inside mesh pocket on the right side
  • large dorsal storage pocket with pocket inside for drink system
  • drink tube opening
  • excellent comfort, mesh fabric on the back
  • well-designed back pocket enables easy packing in a rucksack
  • tube-lead-system for the speed system line
  • deployment handle firmly connected with the inner container
  • EN/LTF certified foam back protection

Photo Gallery

Download files

Included with the harness

Speed Bar
Inner container for rescue system
Carabiners Lockjaw
