MacJet

MacJet	22	24	26	28	31
Zoom flat [%]	88	92.5	96	100	104.5
Area flat [m²]	22.02	24.33	26.21	28.44	31.06
Area projected [m²]	19.06	21.06	22.68	24.61	26.87
Span flat [m]	10.73	11.28	11.71	12.2	12.75
Aspect ratio flat	5.23	5.23	5.23	5.23	5.23
Root cord [m]	2.45	2.57	2.67	2.78	2.91
Cells	58	58	58	58	58
Weight [kg]	5.8	6	6.3	6.6	7
Weight range powered *[kg]	77 - 100	85 - 110	100 - 130	115 - 147	140 - 180
Weight range powered *[lbs]	170 - 220	187 - 243	220 - 287	254 - 324	309 - 397
Min. speed [km/h]	24 - 26	24 - 26	24 - 26	24 - 26	24 - 26
Speed trimmers closed [km/h]	40-43	40-43	40-43	40-43	40-43
Speed trimmers open [km/h]	49-52	49-52	49-52	49-52	49-52
Top speed (accelerator)[km/h]	60 - 63	60 - 63	60 - 63	60 - 63	60 - 63
Glide ratio	8.2	8.2	8.2	8.2	8.2
Min. sink rate [m/s]	1.3	1.3	1.3	1.3	1.3
Certificate	-	-	-	-	-
* powered pilot equipped = weight naked + cca. 35 - 40 Kg (73 - 88 lbs)

Technical Specifications
